Heavy-duty industrial casters carry 1,500 to 10,000 lbs per caster — the workhorse capacity range for warehouse equipment, material-handling carts, fabrication transfers, and assembly-line tooling. Construction shifts to forged or fabricated steel rigs, double-ball-bearing raceways, and hardened axles. Specifying correctly here matters more than in light-duty: a heavy-duty caster failure under load is a safety event, not a service inconvenience.
Specifications
| Capacity range | 1,500–10,000 lbs per caster |
|---|---|
| Common wheel sizes | 6"–10" diameter |
| Tread materials | Polyurethane, phenolic, forged steel, cast iron |
| Mounting | Plate mount (standard 4"x4.5" up to custom 12"x12") |
| Safety factor | Size each caster at 2× its share of the load (3× with ramps, docks or impacts) |
Common Applications
- Warehouse pick carts and tugger trains in 3PL distribution centers
- Steel coil and plate transfer carts in metal fabrication
- Heavy assembly tooling and dies in manufacturing
- Cold storage and freezer carts (with phenolic or stainless tread)
- Aerospace ground-support equipment and avionics test stands
- Custom industrial carts for process and chemical operations
When to Choose Heavy-Duty Industrial Casters
- Total load divided by 4 casters exceeds 1,500 lbs per caster
- Operating environment includes shock loads or transfer impacts
- You need long service life on high-cycle (24/7) operations
- Floor surface is concrete, epoxy, or steel — not delicate tile or tile-finished
- Application requires kingpin-less swivel for shear-load survival
Product Photos
Manufacturer photography from our distribution catalog. Click any photo for a larger view.
Self-Serve Tool
Caster Capacity Calculator
Apply a 2.0 safety factor (3.0 with shock loads) to your application. Same formula our specialists use on the phone — answer in 5 seconds.
Recommended Minimum Capacity
1,000lbsper caster
Recommended Tier
Heavy-Duty Industrial
Brands that fit this capacity
Colson Encore · Durable Superior · P&H
Heavy-Duty Industrial Casters: Series We Supply
Compare capacity per caster, wheel size and tread options, then open a series to see every configuration and request a quote.
| Series | Capacity per caster | Wheel diameter | Tread options | Configurations |
|---|---|---|---|---|
| Colson 4 SeriesColson · Heavy-duty industrial workhorse | 300–1,250 lb | 3.25"–8" | Maxim · Phenolic · HydroTech (Flat) · Performa Rubber (Condutive/Flat) · +27 more | 23,136 |
| Colson 4 Series DefenderColson · Military and tactical heavy-duty | 300–2,000 lb | 4"–8" | CG Max Maroon · CG Max Orange · Trans-forma LT (Round) · Performa Rubber (Condutive/Flat) · +27 more | 7,498 |
| Colson 7 SeriesColson · Heaviest-duty kingpinless industrial | 3,800–20,000 lb | 8"–16" | PY - Polyurethane (Cast Iron Core) · PX - Thick Polyurethane (Cast Iron Core) · PA - Polyurethane (Aluminum Core) · TM - Phenolic · +7 more | 180 |
Ranges come from the manufacturer catalog and vary by configuration. Confirm specifications and availability with our team before purchase.
