Moldon Nylon Aluminumcore Wheels
| Wheel Diameter | Wheel Model | Wheel Bearing Bore | Wheel Bore Less Bearing | Wheel Hub Length | Spanner Bore | Spanner Length | Thread With | Thread Guard | Capacity | Wheel Description | Weight | Swivel Top Plate |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 5" | 3A3-95E | 3/4" | 1-3/16" | 2-3/16" | 1/2" | 2-7/16" | 2" | TG1: A1-2587E | 1000 | Delrin | 4-3/8 | 5.00005.931.3 |
| 5" | 3i3-95E | 3/4" | 1-3/16" | 2-3/16" | 1/2" | 2-7/16" | 2" | 1000 | Roller | 4-3/8 | 5.00005.939.3 | |
| 6" | 3A3-96E | 3/4" | 1-3/16" | 2-3/16" | 1/2" | 2-7/16" | 2" | TG1: F8-1002E | 1200 | Delrin | 5 | 5.00006.931.3 |
| 6" | 3I3-96E | 3/4" | 1-3/16" | 2-3/16" | 1/2" | 2-7/16" | 2" | 1200 | Roller | 5 | 5.00006.939.3 | |
| 8" | 3A3-98E | 3/4" | 1-3/16" | 2-3/16" | 1/2" | 2-7/16" | 2" | TG1: D0-2587E | 1500 | Delrin | 5-5/8 | 5.00008.931.3 |
| 8" | 3I3-98E | 3/4" | 1-3/16" | 2-3/16" | 1/2" | 2-7/16" | 2" | 1500 | Roller | 5-5/8 | 5.00008.939.3 |
