Regent Grip Ring and Grip Neck Stem Models
| Wheel Diameter | Thread With | Wheel Description | Dynamic Load | Mounting Height | Swivel Radius | Part Number |
|---|---|---|---|---|---|---|
| 1-5/8" | 11/16" | Polyolefin | 75 | 2-5/16" | 1-5/8" | PRE16302BO-3E |
| 1-5/8" | 11/16" | Polyolefin | 75 | 2-5/16" | 1-5/8" | PRE16302CO-3E |
| 2" | 13/16" | Soft Rubber | 80 | 2-5/8" | 1-15/16" | PRE20302TZ-3R PRE20222TZ-3R PRE20223TZ-3R PRE20211TZ-3R PRE20273TZ-3R |
| 2" | 13/16" | TPR | 80 | 2-5/8" | 1-15/16" | PRE20302TZ-3E PRE20222TZ-3E PRE20223TZ-3E PRE20211TZ-3E PRE20273TZ-3E |
| 2" | 13/16" | Hard Rubber | 90 | 2-5/8" | 1-15/16" | PRE20302TZ-3H PRE20222TZ-3H PRE20223TZ-3H PRE20211TZ-3H PRE20273TZ-3H |
| 2" | 13/16" | Polyurethane | 90 | 2-5/8" | 1-15/16" | PRE20302TZ-TPU PRE20222TZ-TPU PRE20223TZ-TPU PRE20211TZ-TPU PRE20273TZ-TPU |
| 2" | 13/16" | Solid Polyolefin | 90 | 2-5/8" | 1-15/16" | PRE20302TZ-3ES PRE20222TZ-3ES PRE20223TZ-3ES PRE20211TZ-3ES PRE20273TZ-3ES |
| 2" | 3/4" | Polyolefin | 90 | 2-5/8" | 1-15/16" | PRE20302TZ-3E PRE20222TZ-3E PRE20223TZ-3E PRE20211TZ-3E PRE20273TZ-3E |
| 2" | 7/8" | Vipor | 90 | 2-5/8" | 1-15/16" | PRE20302TZ-VPR01(CG) PRE20222TZ-VPR01(CG) PRE20223TZ-VPR01(CG) PRE20211TZ-VPR01(CG) PRE20273TZ-VPR01(CG) |
| 2-1/2" | 13/16" | Soft Rubber | 80 | 3-1/8" | 2-1/8" | PRE25302TZ-3R PRE25222TZ-3R PRE25223TZ-3R PRE25211TZ-3R PRE25273TZ-3R |
| 2-1/2" | 13/16" | TPR | 80 | 3-1/8" | 2-1/8" | PRE25302TZ-TPR PRE25222TZ-TPR PRE25223TZ-TPR PRE25211TZ-TPR PRE25273TZ-TPR |
| 2-1/2" | 13/16" | Hard Rubber | 95 | 3-1/8" | 2-1/8" | PRE25302TZ-3H PRE25222TZ-3H PRE25223TZ-3H PRE25211TZ-3H PRE25273TZ-3H |
| 2-1/2" | 13/16" | Polyurethane | 95 | 3-1/8" | 2-1/8" | PRE25302TZ-TPU PRE25222TZ-TPU PRE25223TZ-TPU PRE25211TZ-TPU PRE25273TZ-TPU |
| 2-1/2" | 13/16" | Polyolefin | 95 | 3-1/8" | 2-1/8" | PRE25302TZ-3E PRE25222TZ-3E PRE25223TZ-3E PRE25211TZ-3E PRE25273TZ-3E |
| 3" | 13/16" | Soft Rubber | 110 | 3-1/2" | 2-1/2" | PRE30302TZ-3R PRE30222TZ-3R PRE30223TZ-3R PRE30211TZ-3R PRE30273TZ-3R |
| 3" | 13/16" | TPR | 110 | 3-1/2" | 2-1/2" | PRE30302TZ-TPR PRE30222TZ-TPR PRE30223TZ-TPR PRE30211TZ-TPR PRE30273TZ-TPR |
| 3" | 13/16" | Hard Rubber | 120 | 3-1/2" | 2-1/2" | PRE30302TZ-3H PRE30222TZ-3H PRE30223TZ-3H PRE30211TZ-3H PRE30273TZ-3H |
| 3" | 13/16" | Polyurethane | 120 | 3-1/2" | 2-1/2" | PRE30302TZ-TPU PRE30222TZ-TPU PRE30223TZ-TPU PRE30211TZ-TPU PRE30273TZ-TPU |
| 3" | 13/16" | Polyolefin | 120 | 3-1/2" | 2-1/2" | PRE30302TZ-3E PRE30222TZ-3E PRE30223TZ-3E PRE30211TZ-3E PRE30273TZ-3E |
| 3" | 13/16" | Monotech | 120 | 3-1/2" | 2-1/2" | PRE30302TZ-MNT PRE30222TZ-MNT PRE30223TZ-MNT PRE30211TZ-MNT PRE30273TZ-MNT |
| 3" | 13/16" | Vipor | 120 | 3-1/2" | 2-1/2" | PRE30302TZ-VPR01(CG) PRE30222TZ-VPR01(CG) PRE30223TZ-VPR01(CG) PRE30211TZ-VPR01(CG) PRE30273TZ-VPR01(CG) |
| 4" | 15/16" | Soft Rubber | 125 | 4-3/4" | 3-7/16" | PRE40211TZ-3R PRE40273TZ-3R PRE40204TZ-3R |
| 4" | 15/16" | TPR | 125 | 4-3/4" | 3-7/16" | PRE40211TZ-TPR PRE40273TZ-TPR PRE40204TZ-TPR |
| 4" | 15/16" | Hard Rubber | 150 | 4-3/4" | 3-7/16" | PRE40211TZ-3H PRE40273TZ-3H PRE40204TZ-3H |
| 4" | 15/16" | Polyurethane | 150 | 4-3/4" | 3-7/16" | PRE40211TZ-TPU PRE40273TZ-TPU PRE40204TZ-TPU |
| 4" | 15/16" | Polyolefin | 150 | 4-3/4" | 3-7/16" | PRE40211TZ-3E PRE40273TZ-3E PRE40204TZ-3E |
| 4" | 15/16" | Monotech | 150 | 4-3/4" | 3-7/16" | PRE40211TZ-MNT PRE40273TZ-MNT PRE40204TZ-MNT |
| 5" | 15/16" | Soft Rubber | 130 | 5-3/4" | 4-1/8" | PRE50211TZ-3R PRE50273TZ-3R PRE50204TZ-3R |
| 5" | 15/16" | TPR | 130 | 5-3/4" | 4-1/8" | PRE50211TZ-TPR PRE50273TZ-TPR PRE50204TZ-TPR |
| 5" | 15/16" | Hard Rubber | 150 | 5-3/4" | 4-1/8" | PRE50211TZ-3H PRE50273TZ-3H PRE50204TZ-3H |
| 5" | 15/16" | Polyurethane | 150 | 5-3/4" | 4-1/8" | PRE50211TZ-TPU PRE50273TZ-TPU PRE50204TZ-TPU |
| 5" | 15/16" | Polyolefin | 150 | 5-3/4" | 4-1/8" | PRE50211TZ-3E PRE50273TZ-3E PRE50204TZ-3E |
| 5" | 15/16" | Monotech | 160 | 5-3/4" | 4-1/8" | PRE50211TZ-MNT PRE50273TZ-MNT PRE50204TZ-MNT |
| 5" | 15/16" | Precision Brg Monotech | 160 | 5-3/4" | 4-1/8" | PRE50211TZ-MNT33(GG) PRE50273TZ-MNT33(GG) PRE50204TZ-MNT33(GG) |
