Request a Quote It's Fast. It's Friendly. It's Free.
Rigid Top Plate Models
- 1-1/2" Tread Width
- High Strength Steel for added durability
- Dual ball bearing raceway
- Zinc plated finish
- 3/8" diameter nut and bolt axle
- RoHS compliant
Features
- Hospital Equipment
- Utility Carts
- Warehouse Nurseries
- Institutional Equipment
- Office Equipment
- Food Service
Applications
- Brakes: Tread Lock
- Expanding Adapter Casters: Available upon request
Options
| Wheel Diameter | Thread With | Wheel Description | Dynamic Load | Mounting Height | Part Number | Bearing Type |
|---|---|---|---|---|---|---|
| 4" | 1-1/2" | TPR | 250 | 5-5/16" | HDR40149TZ-TPR11(GG) HDR40162TZ-TPR11(GG) | Nylon |
| 4 | 1-1/2 | TPR | 250 | 5-5/16 | HDR40149TZ-TPR81GG) HDR40162TZ-TPR81GG) | Roller |
| 4" | 1-1/2" | TPU | 400 | 5-5/16" | HDR40149TZ-TPU11GG) HDR40162TZ-TPU11GG) | Nylon |
| 4" | 1-1/2" | TPU | 400 | 5-5/16" | HDR40149TZ-TPU81(GG) HDR40162TZ-TPU81(GG) | Roller |
| 4" | 1-1/2" | Phenolic | 400 | 5-5/16" | HDR40149TZ-PHN11(KK) HDR40162TZ-PHN11(KK) | Nylon |
| 4" | 1-1/2" | Phenolic | 400 | 5-5/16" | HDR40149TZ-PHN81(KK) HDR40162TZ-PHN81(KK) | Roller |
| 5" | 1-1/2" | TPR | 250 | 6-5/16" | HDR50149TZ-TPR11(GG) HDR50162TZ-TPR11(GG) | Nylon |
| 5" | 1-1/2" | TPR | 250 | 6-5/16" | HDR50149TZ-TPR81GG) HDR50162TZ-TPR81GG) | Roller |
| 5" | 1-1/2" | TPU | 400 | 6-5/16" | HDR50149TZ-TPU11GG) HDR50162TZ-TPU11GG) | Nylon |
| 5" | 1-1/2" | TPU | 400 | 6-5/16" | HDR50149TZ-TPU81(GG) HDR50162TZ-TPU81(GG) | Roller |
| 5" | 1-1/2" | Phenolic | 400 | 6-5/16" | HDR50149TZ-PHN11(KK) HDR50162TZ-PHN11(KK) | Nylon |
| 5" | 1-1/2" | Phenolic | 400 | 6-5/16" | HDR50149TZ-PHN81(KK) HDR50162TZ-PHN81(KK) | Roller |
