Grip Ring Stem Casters

    Features

  • Zinc plated finish is attractive and durable
  • Full double ball hardened raceways for better performance and greater durability
  • 3/8" hollow axle with lock nut
  • Flush lube grease hole at wheel bearing for greater convenience
  • Colson 45 multi-temp grease lubricates in extreme hot and cold temperatures

    Standard Mounting

  • 5/8" diameter x 2-3/16" long

    Options

  • MTG 5: 3/4" x 2-3/16" long
  • MTG 6: 13/16" x 2-3/16" long
  • MTG 7: 27/32" x 2-3/16" long
  • MTG 8: 7/8" x 2-3/16" long
  • MTG 9: 1" x 2-3/16" long
  • Brakes:Top Lock cannot be combined with NSF. Total Lock locks swivel and wheel simultaneously.
  • Thread Guards: Available on some models
  • Dust Cap: Keeps dust and debris out of the raceway for smoother operation and longer service life
  • Zerk Axle: Grease fitting at cap of axle instead of hollow point. Not available with Top Lock Brake
  • NSF Listed: By special order. All models except thread guards
Wheel Diameter Thread With Capacity Wheel Description Stem Casters Load Height Swivel Radius Weight Bearing Type Swivel Top Plate
2-1/2" 1-1/4" 125 Performa Rubber (Conductive Flat) 4E441522B 3-3/4 2-13/32 1-3/4 Ball 2.02251.445(COND)
2-1/2" 1-1/4" 140 Performa Rubber (Flat) A441522B 3-3/4 2-13/32 1-3/4 Delrin 2.02251.441
2-1/2" 1-1/4" 140 Performa Rubber (Flat) E441522B 3-3/4 2-13/32 1-3/4 Ball 2.02251.445
2-1/2" 1-1/4" 200 Polyolefin C51522B 3-3/4 2-13/32 1-3/4 Delrin 2.02251.53
2-1/2" 1-1/4" 200 Polyolefin E51522B 3-3/4 2-13/32 1-3/4 Ball 2.02251.55
2-1/2" 1-1/4" 250 Polyurethane HI-TECH A91522B 3-3/4 2-13/32 1-1/2 Delrin 2.02251.91
2-1/2" 1-1/4" 250 Polyurethane HI-TECH E91522B 3-3/4 2-13/32 1-1/2 Ball 2.02251.95
2-1/2" 1-1/4" 300 Cast Iron B11522B 3-3/4 2-13/32 2-1/8 Sleeve 2.02251.12
2-1/2" 1-7/16" 300 Phenolic I131522B 3-3/4 2-13/32 1-3/4 Roller 2.02251.319
3" 1-1/4" 150 Rubber HI-TECH B41533B 4 2-21/32 2 Plain 2.03351.42
3" 1-1/4" 200 Polyurethane HI-TECH B91533B 4 2-21/32 2 Plain 2.03351.92
3" 1-1/4" 200 Polyolefin B51533B 4 2-21/32 2 Delrin 2.03351.52
3" 1-15/32" 300 Phenolic I131533B 4 2-21/32 2-3/4 Roller 2.03351.319
3-1/2" 1-5/16" 210 Performa Rubber (Conductive/Round) 4E651523B 4-9/16 2-29/32 2-1/4 Ball 2.03251.565(COND)
3-1/2" 1-5/16" 210 Performa Rubber (Round) A651523B 4-9/16 2-29/32 2-1/4 Delrin 2.03251.561
3-1/2" 1-5/16" 210 Performa Rubber (Round) E651523B 4-9/16 2-29/32 2-1/4 Ball 2.03251.565
3-1/2" 1-1/4" 225 Performa Rubber (Conductive Flat) 4E441523B 4-9/16 2-29/32 2-1/4 Ball 2.03251.445(COND)
3-1/2" 1-1/4" 230 Polyolefin C51523B 4-9/16 2-29/32 2-1/8 Delrin 2.03251.53
3-1/2" 1-1/4" 230 Polyolefin E51523B 4-9/16 2-29/32 2-1/8 Ball 2.03251.55
3-1/2" 1-1/4" 250 Performa Rubber (Flat) A441523B 4-9/16 2-29/32 2-1/8 Delrin 2.03251.441
3-1/2" 1-1/4" 250 Performa Rubber (Flat) E441523B 4-9/16 2-29/32 2-1/8 Ball 2.03251.445
3-1/2" 1-1/4" 250 Polyurethane HI-TECH A91523B 4-9/16 2-29/32 1-3/4 Delrin 2.03251.91
3-1/2" 1-1/4" 250 Polyurethane HI-TECH E91523B 4-9/16 2-29/32 1-3/4 Ball 2.03251.95
3-1/2" 1-1/4" 300 Thermo High Temp THGB51522B 4-9/16 2-29/32 3-1/8 Plain 2.02251.52(HT)
3-1/2" 1-1/4" 300 Cast Iron B11523B 4-9/16 2-29/32 3 Sleeve 2.03251.12
4" 1-1/4" 250 ThermoTech Cushion High Temp 8C161524B 5 3-7/32 3 Teflon 2.04251.613
4" 1-1/4" 250 Performa Rubber (Conductive Flat) 4E441524B 5 3-7/32 2-1/4 Ball 2.04251.445(COND)
4" 1-1/4" 275 Polyolefin C51524B 5 3-7/32 2-1/4 Delrin 2.04251.53
4" 1-1/4" 275 Polyolefin E51524B 5 3-7/32 2-1/4 Ball 2.04251.55
4" 1-1/4" 275 Polyurethane HI-TECH A91524B 5 3-7/32 2 Delrin 2.04251.91
4" 1-1/4" 275 Polyurethane HI-TECH E91524B 5 3-7/32 2 Ball 2.04251.95
4" 1-1/4" 300 Performa Rubber (Flat) A441524B 5 3-7/32 2-1/4 Delrin 2.04251.441
4" 1-1/4" 300 Performa Rubber (Flat) E441524B 5 3-7/32 2-1/4 Ball 2.04251.445
4" 1-1/4" 300 Thermo High Temp THGB51524B 5 3-7/32 3-1/4 Plain 2.04251.52(HT)
4" 1-1/4" 300 Cast Iron B11524B 5 3-7/32 3-1/2 Sleeve 2.04251.12
5" 1-1/4" 250 ThermoTech Cushion High Temp 8C161525B 6-1/16 3-13/16 3 Teflon 2.05251.613
5" 1-1/4" 250 Performa Rubber (Conductive Flat) 4E441525B 6-1/16 3-13/16 3 Ball 2.05251.445(COND)
5" 1-5/16" 250 Performa Rubber (Conductive/Round) 4E651525B 6-1/16 3-13/16 3 Ball 2.05251.565(COND)
5" 1-5/16" 250 Performa Rubber (Round) A651525B 6-1/16 3-13/16 3 Delrin 2.05251.561
5" 1-1/4" 250 Performa Rubber (Round) E651525B 6-1/16 3-13/16 3 Ball 2.05251.565
5" 1-1/4" 300 Polyolefin C51525B 6-1/16 3-13/16 2-3/4 Delrin 2.05251.53
5" 1-1/4" 300 Polyolefin E51525B 6-1/16 3-13/16 2-3/4 Ball 2.05251.55
5" 1-1/4" 300 Polyurethane HI-TECH A91525B 6-1/16 3-13/16 2-1/2 Delrin 2.05251.91
5" 1-1/4" 300 Polyurethane HI-TECH E91525B 6-1/16 3-13/16 2-1/2 Ball 2.05251.95
5" 1-1/4" 300 Cast Iron B11525B 6-1/16 3-13/16 3-3/4 Sleeve 2.05251.12
5" 1-1/4" 325 Performa Rubber (Flat) A441525B 6-1/16 3-13/16 2-3/4 Delrin 2.05251.441
5" 1-1/4" 325 Performa Rubber (Flat) E441525B 6-1/16 3-13/16 2-3/4 Ball 2.05251.445
5" 1-1/4" 325 Thermo High Temp THGB51525B 6-1/16 3-13/16 3-1/2 Plain 2.05251.52(HT)

Brake Options

Total Lock

Available on 3-1/2", 4" and 5" models

Top Lock Brake

Available on all models. Not available with zerk or flush lube axle.

Wheel Selection

Performa Flat Tread
Performa Round Tread
Performa Conductive Flat
Performa Conductive Round
Polyolefin
Thermo High Temp
Thermotech High Temp Cushion
Polyurethane Hi-Tech
Cast Iron
Rubber Hi-Tech
Phenolic
